Appendices 9960 Self-Propelled Peanut Combine
A - 20 06/03/05 MAN091
Accessory Wires
• Circuit codes 900 – 999
• Orange wires except as noted
Circuit Code Number Description
Wire Color
if not orange
902 Horn
909 Climatrak System On
910 Climatrak Sensor Ground
911 Climatrak Sensor Power
913 Climatrak Clutch From Controller
914 Climatrak From Lo Pressure Switch
915 Climatrak Clutch from Hi Pressure Switch
923 Dump Valve Solenoid
924 Lamp and Display Test Signal
926 Climatrak Defog Sig
927 Climatrak Temperature Setpoint
928 Pressurizer Motor Signal
929 Pressurizer Motor
933 Wiper Motor "Lo"
936 Climatrak Auto/Man Fan Switch Sig
937 Climatrak Fan Setpoint Signal
938 Windshield Washer Pump
939 Blower Motor Command (PWM Signal)
942 Left Speaker Signal
943 Left Speaker Ground
944 Right Speaker Signal
945 Right Speaker Ground
964 CAN Lo Yellow
965 CAN Lo Green
980 CAN Ground Black
981 CAN Power Red
