9960 Self-Propelled Peanut Combine Operator’s Station
MAN091 06/03/05 67
Auxiliary Power Outlet
The outlet provides 30 AMP terminals. When
connected, some power terminals provide a
continuous power source. The other terminals
provide power only when the ignition key is
turned to the “accessory” or “start” position.
Cab Ladder
The ladder can be positioned from the ground
or the landing with the indicated lever. Swing
the ladder backward or forward until it locks in
place.
If the ladder latch appears loose, clean out the
latch pin area. Do NOT use oil or grease
around the latch area.
There are three possible positions for the
ladder:
A - The normal field operating position.
B - The position for combines with a small
header, a ladder extension, or duals.
C - The position for truck transport.
Do NOT ride or attempt to climb front or
rear ladders while the combine is moving.
