Operator’s Station 9960 Self-Propelled Peanut Combine
44 06/03/05 MAN091
Activating Header Height Sensing
1. Make sure a properly equipped header is
connected to the combine.
2. Run the engine.
3. Set the road transport disconnect switch to
the field position (top photo). The indicator
life must be off.
4. Press the Header Height Sensing button
on the ACH display on the corner post
(middle photo).
5. Set the Header Engage Switch to “ON”
(top photo).
height
sensing
disconnect
switch
To Next Page
