Air Conditioner/Heater 9960 Self-Propelled Peanut Combine
182 06/03/05 MAN091
Condenser
1. Release the latch (A) and pull out the
rotary screen door (B) (top photo).
2. Pull out condenser and oil cooler (A)
(middle photo).
3. Clean out vacuum ducts (bottom photo).
4. Clean condenser and oil cooler and
replace. Make sure to keep the fins on the
condenser straight.
5. Close and latch rotary screen door.
A – Latch
B – Rotary Screen Door
Turn off the engine and remove the key.
