9960 Self-Propelled Peanut Combine Ground Drive and Rear Axle Service
MAN091 06/03/05 195
Cleaning Hydrostatic Oil Cooler
1. Release the latch (A) (top photo) and pull
out the rotary screen door (B).
2. Pull out oil cooler and condenser to clean
(A) (middle photo).
3. Clean out upper vacuum ducts after
cleaning (bottom photo). Keep the fins on
the cooler straight.
A – Latch
B – Rotary Screen Door
Shut off the engine and remove the key.
