Amadas 9960 - Pressure Sensor Wires

Appendices 9960 Self-Propelled Peanut Combine
A - 18 06/03/05 MAN091
Pressure Sensor Wires
• Circuit Codes 700 – 749
• Purple wires
Circuit Code
Number
Description
702 Main Gearcase Filter Restricted
703 Air Filter Restricted
704 Main Gearcase Pressure
705 Engine Oil Pressure
709 Hydrostatic Charge Pressure
Temperature Sensor Wires
• Circuit codes 750 – 799
• Yellow wires
Circuit Code Number Description
752
753 Engine Coolant Temperature Sensor
754 Engine Coolant Temperature Alarm
755 Main Gearcase Oil Temperature Alarm
756 Hydraulic Oil Temperature Alarm
757 Inlet Air Temperature Sensor
758 Climatrak Outlet Temperature
759 Climatrak Inlet Temperature
761 Climatrak Core Temperature
762 Climatrak Water Valve Actuator Power
763 Climatrak Water Valve Command Signal
764 Climatrak Solar Sensor
765 Climatrak Cab Ambient Temperature
766 Climatrak Water Valve Position Signal
767 Climatrak Diagnostics Select Signal
774 Main Gearcase Oil Temperature Sensor
775 Hydraulic Oil Temperature Sensor
780 Right Control Unit Sensor Ground
