9960 Self-Propelled Peanut Combine Appendices
MAN091 06/03/05 A - 11
Appendix D - Circuit Code
Listings
The circuit numbering system is divided into
groups based on function. Each of these
groups has different colored insulation to
make identification easier. Each wire of
each group is stamped with a circuit code.
Circuit codes are made up of numbers with
optional letter suffixes. A lettered suffix
indicates that there is a splice in the
harness. Each branch of the circuit has a
different suffix.
Circuit Code Colors
The table below lists each function, along
with the wire color and circuit code numbers
included for each.
Circuit Code Number Description Wire Color
1- 49 Power Red
50 - 99 Undefined Undefined
100 - 199 Engine Control White
200 - 249 Propulsion Control Light blue
250 - 299 Undefined Undefined
300 - 399 Separator Control Pink
400 - 499 Header Control Light green
500 - 599 Lighting Brown
600 - 649 Speed Sensors Dark Green
650 - 699 Level Sensors Dark blue
700 - 749 Pressure Sensors Purple
750 - 799 Temperature Sensors Yellow
800 - 849 Position Sensors Tan
850 - 899 Loss Monitors Gray
900 - 999 Miscellaneous Orange
