Monitors 9960 Self-Propelled Peanut Combine
84 06/03/05 MAN091
Elevator Fan Dampener Zero
Calibration
The elevator fan dampener sensor is
calibrated using the elevator fan dampener
procedure. This procedure must be
performed before the combine is first used
and every time the sensor is replaced.
1. Turn the key switch to the RUN position,
or start the combine.
2. Press the diagnostic switch (fig. 1). DIA
displays on the triple display tachometer
(fig. 2).
3. Press the calibration switch. CAL and
conc display on the tachometer.
4. Press the Enter switch. CLOS displays on
the second line of the tachometer.
Fig 1
Fig 2
Fig 3
Fig 4
Fig 5
Fig 6
