Amadas 9960 - Transporting; Drive Wheel Starter Stud; Rear Wheel Bolt Torque

Ground drive and Rear Axle Service 9960 Self-Propelled Peanut Combine
190 06/03/05 MAN091
Transporting
Under certain conditions, the drive tires may
develop a hopping or loping action at transport
speeds. Speeding up or slowing down
eliminates this problem.
Drive Wheel Starter Stud
If a wheel is removed, thread the rim starter
stud into the axle, and
then install the wheel.
This stud can also be used for duals.
Rear Wheel Bolt Torque
Each time a rear wheel is replaced, torque the
wheel bolts 200 N*m (150 lb/ft). Then re-
torque the bolts after one hour of operation.
NOTE! Wheel bolts are M20 x 1.5.
NOTE!
Mount rear tires with t
he offset “in”
and valve stems in the outside.
