Amadas 9960 - Header Height Control

Operator’s Station 9960 Self-Propelled Peanut Combine
40 06/03/05 MAN091
Header Height Control
The Header Height Resume control allows you
to select the position of the feeder house
relative to the combine and return to that
position automatically.
The Header Height Resume system must be
calibrated for each header that is used with the
combine. Calibration instructions are in
Chapter 3, Monitors.
The three buttons on the multi-function handle
indicated in the photo are used to control
header height.
Header height bu
ttons
NOTE!
If both Header Height Resume
and Header Height Sensing are enabled,
button #1 activates Header Height
Resume. Buttons #2 and #3 operate
Header Height Sensing.
1
2
3
