Amadas 9960 - Lighting Circuits

Appendices 9960 Self-Propelled Peanut Combine
A - 16 06/03/05 MAN091
Lighting Circuits
• Circuit Codes 500 – 599
• Brown wires
Circuit Code Number John Deere Description Amadas Description
502 Light Switch "Hazard" Sig
503 Light Switch "Road" Sig
504 Light Switch "Field" Sig
505 Light Switch "Rear" Sig
506 Marker / Tail Lamps
507 Field Lamps
509 Panel Lamps
511 Panel Lamp Power
512 Turn Signal Switch "Right"
513 Turn Signal Switch "Left"
514 Right Turn Lamps
515 Left Turn Lamps
516 Dome Lamp
522 Right Row Finder Lamps Basket Dump Light
523 Left Row Finder Lamps
524 Door Switch
525 Exit Light Signal
526 Road Lamps
528 Auger Light Sig
529 Stubble Lamps
531 Engine service Lamps
533 Grain Tank Lamps
535 Service Light Switch Power
536 Service Lamps
539 Shoe Lamps
559 Rear Lamps
562 Auger Lamps
563 Row Finder Power
564 Right Rear Red Hazard Lamp
565 Left Rear Red Hazard Lamp
572 Stubble Light Sig
579 Dimmer Output Sig
