9960 Self-Propelled Peanut Combine Air Conditioner/Heater
MAN091 06/03/05 181
General Maintenance
Cab Roof Inlet Panel
Clean this panel only with it looks plugged as
follows:
1. Remove the six screws (A) and remove the
panel (B).
2. Clean the panel with compressed air or
water.
3. Replace panel and six screws.
A – Screws
B – Panel
Air is brought in through the left
hand side panel only. The right-
panel does not provide cab air.
