9960 Self-Propelled Peanut Combine Air Conditioner/Heater
MAN091 06/03/05 183
Compressor Drive Belt
To remove the compressor belt:
1. Loosen the locking nut.
2. Loosen the adjusting nut.
3. Loosen the idler using a breaker bar and
socket on bolt (A) to loosen belt tension.
4. Remove the belt.
5. Work belt over fan and remove belt.
A – Bolt
Refrigerant Level
Check refrigerant level every 200 hours as
follows:
1. Bring engine to high idle and set air
conditioner control to maximum cold.
2. Check the sight glass (A). It is normal to
see bubbles at the sight glass when the
compressor clutch is engaged. After the
clutch engages again, the bubbles should
disappear and the sight glass clear after 30
seconds of compressor operation.
3. If the bubbles do not disappear and/or
sight glass does not clear after 30
seconds, see your AMADAS/John Deere
dealer.
A – Sight Glass
Turn off the engine and remove the key.
