9960 Self-Propelled Peanut Combine Operator’s Station
MAN091 06/03/05 71
Steering Wheel Height
To adjust the steering wheel:
1. Loosen the hub.
2. Push or pull on the wheel until it is in
position.
3. Tighten the hub to lock the steering wheel
back in place. Only a slight tightening of
the hub is needed to hold the steering
wheel in place.
Steering Column Tilt
To adjust the steering column tilt:
1. Press down and hold the pedal to release
the lock on the steering column.
2. Move the steering column into the desired
position.
3. Release the pedal to lock the column.
Adjust the steering wheel ONLY when the
combine is stopped.
To prevent momentary loss of control,
adjust the column ONLY when the
combine is stopped.
The column is spring loaded. Do NOT
step on the pedal without holding the
steering wheel in both hands.
