9960 Self-Propelled Peanut Combine Operator’s Station
MAN091 06/03/05 41
Activating Header Height Resume
1. Make sure a properly equipped header is
connected to the combine.
2. Run the engine.
3. Set the road transport disconnect switch to
the field position (top photo). The indicator
life must be off.
4. Press the Header Height Resume button
on the ACH display on the corner post
(middle photo).
5. Set the Header Engage Switch to “ON”
(top photo).
height
resume
disconnect switch
