9960 Self-Propelled Peanut Combine Monitors
MAN091 06/03/05 85
Elevator Fan Dampener Calibration
5. Press and hold the (-) symbol on the
elevator fan dampener switch until the
dampener is completely closed (fig. 1). As
the (-) symbol is pressed, the numbers on
middle line of the display decrease until the
concave is completely closed (fig. 2).
6. Press the calibration switch (fig.3). Zero
(0) displays on the tachometer (fig. 4) for
two seconds, then EOC (fig 5) displays.
Fig 1
Fig 2
Fig 3
Fig 4
Fig 5
