Maintenance 9960 Self-Propelled Peanut Combine
226 06/03/05 MAN091
2000 Hours, Continued
Drain the final drives and refill to within 12
mm (1/2 “) of bottom of check hole. If you
can touch oil with your little finger, you do
not need to add oil.
S
lide the transmission slide tube out of
the block. Remove the block to drain.
Fill at the hole to within 12 mm (1/2 “) of
bottom of hole.
