9960 Self-Propelled Peanut Combine Introduction
MAN091 06/03/05 vii
Specifications (NOTE: Dimensions shown are for a dump basket equipped combine.)
Dimension
Length
Inches (CM)
Width
Inches (CM)
Height
Inches (CM)
Weight
Pounds (KG)
Combine 281 (714) 203 (516) 174 (442) 31,500 (14,300)
Shipping 281 (714) 144 (366) 140 (355) 28,300 (12,800)
6/8 row header 227 (576) 52 (132) 51 (130) 2,600 (1,200)
8/10 row header 304 (772) 52 (132) 51 (130) 3,400 (1,550)
Basket 203 (516) 96 (244) 77 (195) 3,200 (1,450)
Engine
Type.....Turbocharged, air-to-air after cooled
Cylinders...................................................... 6
Displacement.......................................... 6.8L
Horsepower................ 245 HP @ 2400 RPM
High Speed Idle............................ 2540 RPM
Mid Idle ......................................... 1850 RPM
Low Idle........................................ 1300 RPM
Ground Drive
Type.................................. Hydraulic variable
Transmission....................................3-speed
Tires
Main drive (front) ............... 30.5 x 32 (16 ply)
Steering (2-wheel drive)...... 14.9 x 24 (8 ply)
Steering (4-wheel drive)...... 18.4 x 26 (6 ply)
Capacities
Fuel tank................................140 gal (530 L)
Cooling system...........................36 qt. (84 L)
Engine crankcase....................30 qt. (28.5 L)
Transmission.............................10 qt. (9.5 L)
Final Drives..................................9 qt. (8.5 L)
Engine gear case.......................17 qt. (16 L)
Hydraulic fluid.............................36 qt. (34 L)
Peanut bin .......................7,500 lb (3,400 kg)
Separation System
Type................. Disc separator supplied by a
14in. (35 cm) cross induction
fan, 5 retractable spring
overhead separator cylinders
with stripper cylinder
Threshing System
Type...........10% variable speed engine, and
2 speed sprockets for first three cylinders,
variable speed for last two cylinders, 5
spring-toothed cylinders with stripper
cylinder, adjustable retention board, and
adjustable breast spring bars
Cylinder diameter ....................30 in. (76 cm)
Section width.......................103 in. (259 cm)
Collection System
Auger diameter........................12 in. (30 cm)
Pneumatic Conveyor
Area ..........................84 sq. in. (0.054 sq. m)
Fan diameter ...........................28 in. (71 cm)
