File Transfer Operations
153
NetLinx Studio - Instruction Manual
This tab lists the different types of files that can be transferred to the Master or System devices on the bus:
4. Select the type of file that you want to add to the Send tab.
5. Click the Add button. This invokes the Open dialog, with the Files of Type selection already set to the selected file
type.
6. Locate and select the file that you want to add, and click OK to close the Open dialog.
7. In the Enter Device Mapping Information dialog, enter the the proper D:P:S information for the file’s mapping
assignment (FIG. 233).
FIG. 232 Select Files For File Transfer dialog - Other tab
Select Files For File Transfer dialog - "Other" tab file types
Label Description (extension)
IRL/IRV Files IR Files (*.irl, *.irv)
Touch Panel Design File TPDesign3 generated UI files (*.tpd)
NetLinx Source Code File NetLinx Source Code Files (*.src)
Complied NetLinx Source Code File NetLinx Token Files (*.tkn)
Complied Axcess Source Code File Axcess Token Files (*.tok)
TP4 Touch-panel File TPDesign4 generated UI files (*.tp4)
KPD Keypad Touch File Keypad Design generated files (*.kpd)
User IR Database File IR Database files (*.irn)
AMX IR Database File IR Database files (*.irl)
KPB - Keypad Builder File Keypad Builder generated files (*.kpb)
Duet Jar File Duet JAR (module) files (*.jar)
