♦ Wheel alignment computer
♦ ACC Adjustment Device - VAS 6430-
Note
♦ Before driving the vehicle onto the alignment stand, check
whether there is a sufficiently large space between the vehicle
and the ACC Adjustment Device - VAS 6430- . The distance
between the ACC Adjustment Device - VAS 6430- -VAS 6430-
and the vehicle must be 120 cm +/- 5 cm.
♦ If there is not sufficient space, drive vehicle backward on align‐
ment stand in order to be able to use the corresponding space.
♦ Before performing the calibration procedure, check the posi‐
tion of the calibration mirror. The calibration mirror may need
to be adapted before performing the calibration.
♦ The ACC Adjustment Device - VAS 6430- must be adapted
before adjustment procedure. If this is done during the adjust‐
ment procedure, the pre-calibration on the ACC Adjustment
Device - VAS 6430- must be repeated.
• Before beginning the adjustment, check the DTC memory and
correct any malfunctions present.
The adjustment procedure is described here with the ACC Ad‐
justment Device - VAS 6430- .
Note
If there was a previous alignment, the steps under “Calibration
procedure without a previous alignment” should not performed.
Calibration Procedure without a Previous Alignment
– Connect battery charger, refer to ⇒ Rep. Gr. 27 .
– Activate vehicle lift mode, refer to
⇒ “2.3 Vehicle Lift Mode”, page 209 .
– Select the ACC calibration button on the alignment computer.
– Install quick clamps on the rear wheels.
– Install measuring sensors on the rear wheels.
– Perform a rim run-out compensation on the rear wheels.
Note
The ACC Adjustment Device - VAS 6430- must not be moved on
the calibration beam.
Calibration Procedure with or without a Previous Alignment
– Remove license plate holder, refer to ⇒ Rep. Gr. 63 .
– Remove all contamination on sensor lens and inside of license
plate holder.
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
264 Rep. Gr.44 - Wheels, Tires, Wheel Alignment
