Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
12 - Reservoir
13 - Bolt
9 Nm
14 - Nut
9 Nm
15 - Bracket
For reservoir.
16 - Bolt
9 Nm
17 - Return Line
Tighten the union nut to 32 Nm.
Note location on hydraulic oil cooler, refer to ⇒ “6.2 Lines and Hoses Overview”, page 338 .
Secure, refer to ⇒ “6.2 Lines and Hoses Overview”, page 338 .
18 - Clip
19 - Bolt
9 Nm
20 - Bracket
With washer and rivet.
For hydraulic oil cooler on condenser.
Clip lines from hydraulic oil cooler in bracket.
21 - Bracket
With washer and rivet.
For hydraulic oil cooler on condenser.
Insert hydraulic oil cooler in bracket.
22 - Hydraulic Oil Cooler
Removing and Installing, refer to ⇒ “10 Hydraulic Fluid Cooler, Removing and Installing”, page 393 .
23 - Wiring Bracket
24 - Seal
Always replace.
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
6. Power Steering Pump, Hydraulic Pipes and Reservoir 337
