9 - Self-Locking Nut
❑ 105 Nm
❑ Always replace if removed.
10 - Wheel Bearing
❑ Removing and Installing, refer to
⇒ “5.5 Wheel Hub and Wheel Bearing, Removing and Installing”, page 94 .
Caution
•Avoid contaminating with
dirt and damaging the
seal when setting down/
storing, refer to
⇒ Fig. ““Avoid contami‐
nating with dirt and dam‐
aging the seal when set‐
ting down/storing.”“ ,
page 83 .
11 - Locking Ring
❑ Check for proper seating.
12 - Self-Locking Nut
❑ 500 Nm
❑ Always replace if removed.
❑ Before assembling, coat contact surface with Assembly Paste .
13 - Wheel hub
❑ Removing and Installing, refer to
⇒ “5.5 Wheel Hub and Wheel Bearing, Removing and Installing”, page 94 .
14 - Bolt
❑ 20 Nm
15 - Cover Plate
16 - Wheel Bearing Housing
❑ There are different versions depending on the model year, refer to ⇒ page 83 , allocation, refer to the
Parts Catalog.
❑ Removing and Installing, refer to ⇒ “5.4 Wheel Bearing Housing, Removing and Installing”, page 93 .
❑ Conical bores must be free of grease and oil.
❑ If necessary, clean using dry rag, do not use cleaning agents.
17 - Self-Locking Nut
❑ 85 Nm
❑ Always replace if removed.
18 - Bracket
19 - Bolt
❑ 20 Nm
20 - Upper Control Arm
❑ Conical pin must be free of grease and oil.
❑ If necessary, clean using dry rag, do not use cleaning agents.
21 - Bracket
22 - Bolt
❑ 9 Nm
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
82 Rep. Gr.40 - Front Suspension
