229R5910032 /00 Freya
Image 11–27
By default there are four types of devices able to execute an action:
• GPIO (General Purpose Input/Output) : this device allows to interact with the 8 GPO outputs of the
ICMP.
• PLAYER: Allows to access a set of commands tat will be sent to the ICMP Player.
• PROJECTOR: Allows to access the available projector macros.
• UDP: Allows to send text commands to devices.
Other devices can be added via the devices configuration page. For the complete list of devices and
correlated commands, see “Devices and commands”, page 222.
6. Click on the command drop down and select the desired command (reference 5). The command list
changes depending on the selected device.
Some commands require additional parameters such as channel number or pulse duration for GPIO, the
name of the macro to be executed by the projector. In all these cases, extra fields are displayed in the
parameter pane (reference 9).
7. Enter a delay before a command is executed (reference 10).
8. Click the Save icon.
How to remove an action?
1. While creating or editing an Input cue, click on the trash bin icon of the undesired action (reference 11).
Configuration - Media server automation
