Barco Freya - Page 342

R5910032 /00 Freya342
10/100 Base-T — RJ45 port 1000 Base-T — RJ45 port
Pin Pair Color
Description Description
3 2 white/orange RXD+ RX0+
4 1 blue — TX1+
5 1 white/blue — TX1-
6 2 orange RXD- RX0-
7 4 white/brown — Rx1+
8 4 brown — RX1-
General Purpose Input (GPI):
GPI 1-4
RJ-45 pin nr
Definition GPI Name
1 GPI 1 P GPI 1, reserved for 3D L/R
input reference
2 GPI 1 N
3 GPI 2 P GPI 2, reserved for 3D L/R
display reference
4 GPI 2 N
5 GPI 3 P GPI 3, reserved for power
control
6 GPI 3 N
7 GPI 4 P GPI 4 (free)
8 GPI 4 N
GPI 5-8
RJ-45 pin nr
Definition GPI Name
1 GPI 5 P GPI 5 (free)
2 GPI 5 N
3 GPI 6 P GPI 6 (free)
4 GPI 6 N
5 GPI 7 P GPI 7 (free)
6 GPI 7 N
7 GPI 8 P GPI 8 (free)
8 GPI 8 N
General Purpose Output (GPO):
GPO 1-4
RJ-45 pin nr
Definition GPI Name
1 GPO 1 P GPO 1, reserved for 3D L/R
output reference
2 GPO 1 N
3 GPO 2 P GPO 2, reserved
4 GPO 2 N
5 GPO 3 P GPO 3, reserved
6 GPO 3 N
7 GPO 4 P GPO 4 (free)
Pin configurations
