343R5910032 /00 Freya
GPO 1-4
RJ-45 pin nr
Definition GPI Name
8 GPO 4 N
GPO 5-8
RJ-45 pin nr
Definition GPI Name
1 GPO 5 P GPO 5 (free)
2 GPO 5 N
3 GPO 6 P GPO 6 (free)
4 GPO 6 N
5 GPO 7 P GPO 7 (free)
6 GPO 7 N
7 GPO 8 P GPO 8 (free)
8 GPO 8 N
Peripheral Port
Pin Name
1 +5V
2 SCL
3 SDA
4 +24V
5 GND
3D connector
Pin Name Pin Name
1 +12V 9 +12V
2 Grnd 10 3D Input Reference -
3 Grnd 11 3D Display Reference +
4 RS232 RX 12 3D Display Reference -
5 RS232 TX 13 CONN_3D MODE -
6 CONN_3D_MODE + 14 CONN_SYNC -
7 CONN_SYNC + 15 -
8 3D Input Reference +
Pin configurations
