Design and Operation
Instruction handbook bmaXX 5000
Document No.: 5.09021.19
103
of 346
4
4.4.3.2 LED display controller
Naming on the
front plate
Internal identification Meaning
H11 1.1 green,
1.1 red
Axis 1: Torque direction
H11 green: Positive torque direction
H11 red: Negative torque direction
H12 1.2 green,
1.2 red
Axis 1: Power on / pulse enable 24 V available
H12 green: Power ON
H12 red:
H13 1.3 Axis 1: Current limit
H13 red: Device operates on current limit
H14 1.4 Axis 1: Error display
H14 red: Device error message
H21 2.1 green,
2.1 red
Axis 2: Torque direction
H21 green: Positive torque direction
H21 red: Negative torque direction
H22 2.2 green,
2.2 red
Axis 2: Power on / pulse enable 24 V available
H22 green: Power ON
H22 red:
H23 2.3 Axis 2: Current limit
H23 red: Device operates on current limit
H24 2.4 Axis 2: Error display
H24 red: Device error message
