Display and operating elements
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
102
of 346
4.4
4.4.3.1 7-segment display controller
Refer to parameter manual for detailed description of drive states and state transitions.
0: Low, 1: High
Display State
drive manager
Meaning
0
NOT READY TO SWITCH ON Drive message „Not ready for switching power on“
1
SWITCH-ON INHIBIT Inhibit voltage, e.g. quick stop active
2
READY TO SWITCH ON Drive shutdown
Control word: xxxx x110
Pulse enable = 0
Quick stop = 1 (low active)
3
SWITCHED ON Control word: xxxx x111
Pulse enable = 1
Quick stop = 1
4
OPERATION ENABLED Control word: xxxx 1111
Pulse enable = 1
Quick stop = 1
5
BETRIEB SPERREN AKTIV
6
OPERATION INHIBIT ACTIVE Pulse enable = 0
7
QUICK STOP ACTIVE Quick stop = 0 (low active)
E
ERROR RESPONSE ACTIVE
F
ERROR Error message
Reset via control word 0xxx xxxx
or reset stored errors 0
➝ 1
P
Parking axis
NOTE!
In addition the error No. is displayed, refer to ZBM51XX and BM53XX error detec-
tion– as from page 253.
