Electrical connections
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
178
of 346
7.14
(max. allowable number of axis units: 12)
Notes for the laying of the signal bus cable:
Figure 90: Laying of the signal bus cable
1 Fix the ribbon cable bracket at the first unit from the left side always on this place. Rib-
bon cable leftover as a loop between the ribbon cable bracket and the connector.
2 From the second unit from the left side on fix the ribbon cable bracket always on this
place.
Ribbon cable bracket see ZSpare parts– as from page 299.
X300 (SELV/PELV) Connection method
Signal bus BM50XX
BM51XX
BM53XX
Configured cable
