Connections on the front side
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
186
of 346
7.15
Pin assignment X2
1)
only hardware configuration controller 01, BM53XX-XXXX-XXXX-XX01
refer to ZType code– as from page 90.
2)
hardware configuration controller from 06, BM53XX-XXXX-XXXX-XX06
refer to ZType code– as from page 90.
Pin Nr. BM53XX
Single axis
BM53XX
Double axis
1 N.C.
1)
+24 V (supply digital IN/OUT)
2)
2 Ready-to-operate Ready-to-operate 1, axis 1
3 Ready-to-operate Ready-to-operate 1, axis 1
4 Digital output 1
5 Digital output 2
6 Digital output 3
7 Digital output 4
8 N.C.
1)
+24 V (supply digital IN/OUT)
2)
9 N.C. Ready-to-operate 2, axis 2
10 N.C. Ready-to-operate 2, axis 2
11 +24 V (supply digital IN/OUT)
12 M24V (supply digital IN/OUT)
13 (fast) digital input 1, Schnellhalt (fast) digital input 1,
quick stop 1, axis 1
14 (fast) digital input 2 (fast) digital input 2,
quick stop 2, axis 2
15 Digital input 3
16 Digital input 4
17 Digital input 5
18 Digital input 6
19 Digital input 7 Digital input 7,
pulse enable 2, axis 2
20 Digital input 8, pulse enable Digital input 8,
pulse enable 1, axis 1
