Cabling
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
276
of 346
11.1
SIE The connection cable is not offered by Baumüller and must be made by the user:
1 Use the following materials:
m Cable: LiYCY 2 x (2 x 0.14 mm²) + 1x0.34 mm² Cu braiding.
m D-sub connector: 9-pin, female (SIE side)
m E.g. D-sub connector: 26-pin, male (b maXX 5000 side)
m Cables must be of twisted pair wire (DAT+/DAT-, CLK+/CLK-) from SSI encoder em-
ulation to further master control systems
2 Connect
m the cable shield with the connector shell of the D-sub male/D-sub female connector
m the 9-pin female connector (SIE side) with the cable
m e.g. the 26-pin D-sub male connector (bmaXX5000 side, pin assignment see
ZConnecting cable for sine/square-wave incremental encoder– on page 274) with
the other cable ending.
Figure 124: Connection cable IEE with bmaXX 5000
NOTE!
On the SSI encoder emulation side data and clock cables (DATA+/DATA- and CLK+/
CLK-) are terminated with 120 . Additional termination resistors are required on the
CNC side if this resistors are not provided by its manufacturer.
1
5
9
8
7
1
20
19
13
3
