Accessories and spare parts
Instruction handbook b maXX 5000
Document No.: 5.09021.16
277
of 328
11
Electrical data
Rated voltage max. 550 V, rated frequency 50/60 Hz, flat connector, IP 00, 
rated voltage 400 V, u
K
= 4% (50 Hz) / 4.8% (60 Hz), 
operating temperature for I
AC
up to 80 A up to 45 °C and for I
AC
over 80 A up to 40 °C, 
with a derating of the current by 1% per °C up to 55 °C.
Power choke Part No. I
AC
[A]
I
DC
[A]
L
[m
H]
Power
loss
[W]
Weight
[kg]
Use in operation at 
rated power
1)
BK3-0025/0030 368377 25 30 1.18 65 6 BM5030, BM5031
BK3-0040/0050 368378 40 50 0.72 79 7 BM5032
BK3-0080/0100 368380 80 100 0.36 134 12 BM5043
BK3-0165/0200 368382 165 200 0.18 192 23 BM5044
1)
With minimal output in continuous operation, chokes with lower rated currents are also usable. Chokes with larger rated currents are
necessary for cyclical utilization of the overload capacity of the devices. If overcurrent is only needed momentarily and non-recurringly
(once per hour, for a maximum of 60 s), then the chokes suggested for operation at the rated power are also sufficient.
UL approval
The chokes are design-tested in accordance with UL (e.g. UL1561) and s
ignified by the
„ú“ “ symbol.
Dimensions
BK3- Part No. I
AC
[A]
I
DC
[A]
a
[mm]
b
[mm]
c
[mm]
d
[mm]
e
[mm]
f  g
[mm]
Flat connector
Cu terminals
[mm  mm]
0025/0030 368377 25 30 155 130 132 130 72 8 12 20 2
for M6
0040/0050 368378 41 50 190 120 158 170 58 8 12 20 2
for M6
0065/0080 368379 66 80 190 140 158 170 78 8 12
20 2 for M6
0080/0100 368380 82 100 230 165 202 180 98 8 12 25 3
for M8
0115/0140 368381 115 140 230 190 202 180 122 8 12 25 3 fo
r M10
0165/0200 368382 164 200 240 195 211 190 125 11 15 25 3 fo
r M10
0195/0240 368383 197 240 265 195 230 215 126 11 15 25 3 fo
r M10
0275/0340 368384 297 340 300 225 271 240 145 11 15 30 5 fo
r M10
0365/0450 368385 369 450 360 220 320 310 125 11 15 40 5 fo
r M10
0450/0550 368386 451 550 360 260 320 310 140 11 15 50 5 fo
r M12
0530/0650 368387 533 650 360 260 320 310 140 11 15 50 5 fo
r M12
0615/0750 368388 615 750 420 285 375 370 151 11 15 60 5 fo
r M12
0750/0920 368389 754 920 420 285 375 370 151 11 15 60 5 fo
r M12
0900/1100 368390 902 1100 420 285 380 370 166 11 15 60 1
0 for M12
