Electrical connections BM5030 with safety function
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
330
of 346
D.6
D.6 Electrical connections BM5030 with safety function
BM5030-XX2X-...
Figure 139: Electrical connections of BM5030-XX2X-...
Potential-free
electronic switch
Potential-free
electronic switch
DC link
Mounting wall
M24V
Inhibit input
reserved
Reset
Error
Ready-to-operate
+24V
GND 24V
STO input A
GND for STO input A
STO input B
GND for STO input B
Power supply
Ready-to-operate
Error
Connection for additional
DC link capacitance
connected upstream STO,
e.g. BM5-CAP
