Uni-Probe LB 490
BERTHOLD TECHNOLOGIES GmbH & Co. KG
2 – 267
Volume 2 6 Technical Drawings
2
6.3.7 Bracket for Super-Sens
Please keep in mind that for a continuous level measurement you
need a sufficiently large section of the radiation window to allow an
unobstructed radiation channel.
250
180
240
<160
Ø18
~20
250
180
302
602
240 288
Side view Top view
With installed Super-Sens detector
Bracket
Radiation path
Radiation path
Radiation path
Radiation path
Bracket
Radiation window
Radiation window
Section for radiation
window
Section for radiation
window
