Uni-Probe LB 490
BERTHOLD TECHNOLOGIES GmbH & Co. KG
5 – 467
Volume 5 4 Menu Overview
5
4.2.22 SERVICE  I/O TEST  STATUS DIGITAL
INPUTS
Test inputs and outputs.
 Check the status of the digital inputs 1 - 3.
Short a digital input to the terminals and check the status indi-
cated in the dialog (open/closed).
4.2.23 SERVICE  I/O TEST  DIG. OUTPUT TEST
Test digital outputs.
DO 1 … DO 4  Select a digital output and then click OK to check it.
DONE  Select DONE and then click OK to terminate the test.
