Uni-Probe LB 490
BERTHOLD TECHNOLOGIES GmbH & Co. KG
5 – 503
Volume 5 5 Calibration with SIMATIC PDM
5
 Confirm the dialog with OK.
This completes the full calibration.
5.3.4 Check Calibration
 Select DEVICE  CALIBRATION  CHECK CURVE.
The calibration is checked.
If an error has been detected during calibration, a window
opens describing the type of error.
This completes the calibration check and the two-point cali-
bration.
Tip
A test calculation should be performed after every calibration to
ensure that the calibration data are plausible and the device has
been set up correctly (see page 5–466).
