Experiment Builder
Symbol Description
Sample position
Reagent position
Wash position
Unassigned position
Table 23. Plate map symbols, continued
PMT Control Panel
The PMT Control panel in the Settings workspace allows you to control initial settings related to lasers
and detectors. These settings can be adjusted later after acquisition begins.
User Guide | 85
