The Toolbar
Some of these tools also appear in the Analysis tab toolbar. For more information, see Analysis
Toolbar on page 305.
Batch Tools
The batch tools appear in the toolbar of the Settings screen. These tools allow you to set gate limits for
all experimental samples or for selected positions. Sampling occurs until the specified gate limits are
reached.
Tool Function
Region
Allows you to specify the region to which the gate will apply.
Limit
Allows you to specify a gate limit.
Apply the gate limit to experimental samples, as opposed to compensation controls.
Apply the gate limit to the selected sample positions.
Table 26. Batch toolbar tools and their functions
Quick Action and System Action Tools
A quick-action tool is available in the Acquisition tab toolbar.
Button Function
Analyze
— opens the most recent run list in the analysis tab. This is useful when you
want to perform auto-compensation in the current run list.
Table 27. Quick Action button and its function
System actions tools are available in the Acquisition tab toolbar; the items available depend on
instrument status.
User Guide | 95
