BRP Evinrude E-TEC G2 - Reed Plate Assembly and Throttle Body; Service Charts

146
Fuel System
Service Charts
Service Charts
Reed Plate Assembly and Throttle Body
E
35 to 60 In. lbs.
(4 to 6 N·m)
35 to 60 In. lbs.
(4 to 6 N·m)
F
30 to 42 in. lbs.
(4 to 5 N·m)
84 to 106 In. lbs.
(10 to 12 N·m)
84 to 106 In. lbs.
(10 to 12 N·m)
84 to 106 In. lbs.
(10 to 12 N·m)
009305
E Red Ultra Lock
F Blue Nut Lock
Start at center and use
a spiral torque pattern
