BRP Evinrude E-TEC G2 - Water Pump and Gearcase Housing

354
Gearcase
Service Charts
Water Pump and Gearcase Housing
A
A
A
B
A
B
106 to 127 In. lbs.
(12 to 14 N·m)
A
A
E
15 to 17 Ft. lbs.
(20 to 23 N·m)
10 to 14 In. lbs.
(1.2 to 1.6 N·m)
18 to 24 In. lbs.
(2 to 2.7 N·m)
18 to 24 In. lbs.
(2 to 2.7 N·m)
60 to 84 in. lbs.
(7 to 10 N·m)
X
009311A
A Triple-Guard Grease
B Gasket Sealing Compound
D Moly Lube
E Red Ultra Lock
G Needle Bearing Grease
X See Service Manual Text
