360
Gearcase
Propeller Service
ward, the propeller rotates in a left-hand (coun-
terclockwise) direction as viewed from the rear.
Propeller Hardware Installation
IMPORTANT: Depending on propeller style, dif-
ferent thrust bushings, spacers, and cotter pin
keepers are used. See the Evinrude/Johnson Gen-
uine Parts and Accessories Catalog for correct
propeller hardware.
Apply Triple Guard grease to the splines of the
propeller shaft before installing the propeller.
When installing a propeller with an interchange-
able hub, follow the instructions provided with the
propeller.
IMPORTANT: After installation, make sure out-
board is in NEUTRAL and carefully spin propeller.
Propeller must turn freely and should not spin off
center. If propeller appears to wobble, check for
possible bent propeller shaft.
5008933-04
WARNING
For multiple-outboard installations, always
check to be sure propellers are installed on
the correct engines before aggressively oper-
ating the boat.
WARNING
When servicing the propeller, always shift the
outboard to NEUTRAL position, turn the key
switch OFF and remove the key, so the out-
board cannot be started accidentally.
Standard
Rotation
Counter
Rotation
1. Anode screw
2. Anode
3. Cotter pin
4. Keeper
5. Nut
6. Thrust bushing
7. Torsion bushing
8. Thrust washer
5008933-05
1 2 3 4 5 6 7 8
