Engine Cover and Frame Service
Cover Installation
62
Cover Installation
Install the front cover. Install the upper screws
first. Tighten the screws 18 to 30 in. lbs. (2 to 3
N·m).
Apply Silicone Spray, P/N 775630, onto a shop
towel and liberally apply to the port and starboard
rubber seals.
Install the port and starboard covers.
Tighten the port and starboard side cover screws
one-quarter turn.
5009420_03-10
1. Rubber seal 5008559_19
5009420_03-09
Port Side Shown 5008559_08
