BRP Evinrude E-TEC G2 - Page 63

63
Engine Cover and Frame Service
Cover Installation
3
Install the rear cover.
Install one screw at the top of the rear cover.
Tighten the screw 18 to 30 in. lbs. (2 to 3 N·m).
Install the retainer.
Install the top cover.
Push down on the rear of the top cover to secure
the latch.
5008559_07
1. Screw
2. Retainer
5008559_06
1
2
5008559_05
5008559_05
