BRP Evinrude E-TEC G2 - Trim & Tilt Manifold Assembly (Non-DPS Models)

300
Stern and Swivel
Service Charts
Trim & Tilt Manifold Assembly (Non-DPS Models)
X
18 to 20 Ft. lbs.
(24.4 to 27 N·m)
4
3
1
2
60 to 84 In. lbs.
(7 to 10 N·m)
18 to 20 Ft. lbs.
(24.4 to 27 N·m)
59 to 70 Ft. lbs.
(80 to 94 N·m)
60 to 84 In. lbs.
(7 to 10 N·m)
60 to 84 In. lbs.
(7 to 10 N·m)
22 to 30 In. lbs.
(2.5 to 3 N·m)
AA
009432
E Red Ultra Lock
X See Service Manual Text
AA No-Ox Grease
