27
Routine Service
Maintenance
2
After the outboard shuts itself off, turn key switch
OFF, then detach garden hose.
IMPORTANT: When finished, leave the outboard
in vertical position long enough to completely drain
the powerhead.
Additional Recommendations
• Top off oil reservoir.
• Remove and inspect propeller.
• Clean and grease propeller shaft.
• Inspect outboard, steering system, and con-
trols. Replace all damaged and worn compo-
nents.
• Touch up painted surfaces as needed. Coat
outer painted surfaces with automotive wax.
• Remove battery(s) from boat. Store in a cool,
dry location. Periodically charge battery(s) while
stored. Refer to manufacturer’s maintenance
recommendations when servicing batteries.
• Store outboard in upright (vertical) position.
• Check for fuel leakage.
ICON Touch 7.0 CTS
1. Menu/Settings
2. Winterize Tab
356596-36
ICON 3.5C
1. Mode Select
216762-12
ICON Pro 5 inch Digital Gauge
1. Mode button
008686
I-Command 3.5 inch Digital Gauge
1. Menu button
008191
WARNING
Failure to check for fuel leakage could allow a
leak to go undetected, resulting in fire or
explosion.
