Stern and Swivel
Dynamic Power Steering (DPS)
302
detects a pressure differential between the two
pressure sensors and turns ON the DPS pump
providing steering assistance.
The DPS module also monitors the steering posi-
tion sensor. As the outboard approaches the
steering system stop, the DPS module turns OFF
the DPS pump to maximize system efficiency.
The DPS Module monitors Port Pressure Sensor
(PTPS) voltage and Starboard Pressure Sensor
(STPS) voltage.
If PTPS voltage is less than 0.12 V, the EMM:
If PTPS voltage is greater than 4.6 V, the EMM:
If STPS voltage is less than 0.12 V, the EMM:
If STPS voltage is greater than 4.6 V, the EMM:
If Steering Sensor (STS) voltage is less than
0.12 V, the EMM:
If STS voltage is greater than 4.88 V, the EMM:
Stores fault code 212
Engine Monitor: CHECK ENGINE display ON
Stores fault code 213
Engine Monitor: CHECK ENGINE display ON
Stores fault code 214
Engine Monitor: CHECK ENGINE display ON
Stores fault code 215
Engine Monitor: CHECK ENGINE display ON
Stores fault code 220
Engine Monitor: CHECK ENGINE display ON
Stores fault code 221
Engine Monitor: CHECK ENGINE display ON
