When the ERR indicator (orange) is on

The hardware of the printer is in an abnormal condition.

Contact your local authorized Canon dealer to request service.

When all the indicators are off

"All the Indicators on the Network Interface Are Off"

㻝㻜㻣㻌㻛㻌㻠㻡㻞
