FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
MAINTENANCE
154 ORIGINAL INSTRUCTIONS
Fault Message Probable cause Action Type
EJECT.SYSTEM JAM
Ejection system jammed
Check that the ejector is not blocked in ejection
position or that no product is jammed in front of
the Ejection Confirmation sensor.
Sensor connected to EJ.
CONFIRMATION input
faulty or disconnected
Check the correct sensor position, electrical
connections and installation parameters; simulate
the normal input activation and verify (in I/O Status
Menu) that its status changes correctly. If the
problem persists, contact Assistance Service.
EJECT.OUT OF ORDER
Only with CEIA ejector
with double sensor
Ejector in incorrect position
Check that the ejector is not blocked and that it is
correctly installed.
Self-diagnosis not correctly
set
Check that the ejector position check diagnosis is
correctly programmed for the application.
Sensors connected to EJ.
CONFIRMATION and EJ.
POSITION CHECK inputs
faulty or disconnected
Check the sensor electrical and mechanical
connections. If the problem persists, contact
Assistance Service.
EJECT CHECK FAULT
Product passed in front of the
Ejection Check sensor during an
ejection
Remove the product not ejected.
Self-diagnosis not correctly set
Adjust the diagnosis accuracy depending on the
size of product transiting in front of the sensor.
Sensor connected to EJECTION
CHECK input faulty or disconnected
Check the correct sensor position and electrical
connections, simulate the normal input activation
and verify its status change in I/O Status Menu. If
the problem persists, contact Assistance Service.
SYNC PHOTOC.FAULT
Product jammed in front of the
Synchronization Photocell sensor
Remove the jammed product.
Self-diagnosis not correctly set
Set the sensor diagnosis parameter depending on
the size of product transiting in front of the sensor.
Sensor connected to PHOTOCELL
input faulty or disconnected
Check the correct sensor position and electrical
connections, simulate the normal activation and
verify its status change in I/O Status Menu. If the
problem persists, contact Assistance Service.
CHECK PHOTC.FAULT
Product jammed in front of the
Ejection Check sensor
Remove the jammed product.
Self-diagnosis not correctly set
Set the sensor diagnosis parameter depending on
the actual product transit in front of the sensor.
Sensor connected to EJECTION
CHECK input faulty or disconnected
Check the correct sensor position and electrical
connections, simulate the normal activation and
verify its status change in I/O Status Menu. If the
problem persists, contact Assistance Service.
