CDM-625A Advanced Satellite Modem MN-CDM625A
Front Panel Operation Revision 4
6–25
6.2.1.4.3 CONFIG: Rx  FEC
Dec=Vit (Vit,Seq,TCM,TPC,LDPC,VFEC,ULL)
Reed-Solomon=Off (Off,On) ()
Use the
◄ ►arrow keys to select Dec (Decoder) or Reed-Solomon (or Diff Encoder – see Note 1
below). Press ENTER.
On the top line –Use the
▲▼ arrow keys to select an available Decoder option (shown in
parentheses). Press ENTER. Valid selections are:
► None (i.e., uncoded)
► Vit (Viterbi)
► Seq (Sequential)
► TCM (Trellis Coded Modulation)
8-PSK Rate 2/3 only (FAST option)
► TPC (Turbo Product Codec)
(Hardware option)
► LDPC (Low Density Parity
Check) (Hardware option)
► VFEC (VersaFEC)
► VF2L (VersaFEC-2 Long Block)
► VF2S (VersaFEC-2 Short Block)
► ULL (VersaFEC Ultra-Low Latency)
1) When you select None as the Encoder setting, the bottom line of the display changes
from Reed-Solomon to Diff Encoder (Differential Encoding).
2) The TPC (Turbo) and LDPC encoding selections appear only when you install the
TPC/LDPC hardware option.
On the bottom line – When Reed-Solomon is present, use the
▲▼ arrow keys to select it as On
or Off. Press ENTER to continue.
CONFIG: Rx  FEC  Reed-Solomon On
Reed-Solomon Decoding =IESS-310(219/201)
(Standard(126/110),IESS-310(219/201)) ()
Use the
▲▼ arrow keys to select an available parameter. Press ENTER. Depending on the
Framing mode, valid selections are:
►
IESS-310, open or closed network
219/201
► IBS or D&I 126/112
► EDMAC or EDMAC2, closed network 200/180
►
IDR, open network
225/205, 219/201 or 194/178
► ESC++ or D&I++, closed network 126/112
► Unframed closed network:
○ Comtech standard 220/200
○ Legacy EF Data
225/205, with V.35 scrambling
Otherwise, when Diff Encoder is present, use the ▲▼ arrow keys to select it as On or Off. Press
ENTER to continue.
