CDM-625A Advanced Satellite Modem MN-CDM625A
CDM-625A ODU (Transceiver, BUC, LNB) Operation Revision 4
10–15
10.3.3.3.3.1 ODU: FSK-control  CSAT
The CSAT menus that follow assume that you have already selected, and the
system has identified, a (standalone) CSAT connected via the rear panel Rx IF port.
When the following menu selections are made:
• ODU: FSK-control

CSAT
• ODU: FSK-control

2CSATs

CSAT#1
• ODU: FSK-control

2CSATs

CSAT#2
You are directed to a common submenu branch:
CSAT-5060/050 V1.02
Configuration Monitor Alarms Info()
For clarity, this common submenu branch and its nested menus are defined in this
section. (CSAT#X denotes CSAT#1 or CSAT#2.)
Use the
◄ ►arrow keys to select Configuration, Monitor, Alarms, or Info, and then press
ENTER.
10.3.3.3.3.1.1 ODU: FSK-control  CSAT (2CSATs  CSAT #X) 
Configuration
Configuration settings:
Tx Rx LNA Misc ()
Use the
◄ ►arrow keys to select Tx, Rx, LNA, or Misc, and then press ENTER.
10.3.3.3.3.1.1.1 ODU: FSK-control  CSAT (2CSATs  CSAT #X) 
Configuration
 Tx
Tx: Fq=6247.0 MHz Att=23.00 dB Amp=On
Mute=Unmuted Slope: xxx, Cal ()
Use the
◄ ►arrow keys to select a setting, and then use the ▲▼ arrow keys to change that
setting:
Selection Setting
Fq
(Tx Frequency)
3625-4200 MHz, in steps of 1.0 or 2.5 MHz
At
(Tx Attenuation )
0 to 25 dB, in increments of .25dB
Amp
(Amplifier setting ) Off or On
