CDM-625A Advanced Satellite Modem MN-CDM625A
Front Panel Operation Revision 4
6–90
6.2.4.10 Info: Remote
Remote-Control= Local Address= 0000
Interface= RS-232 9600 baud 8N1
This screen displays if the unit is in Local, Remote or Ethernet (IP) mode; the electrical interface
type selected; the unit’s address; and the active baud rate.
6.2.4.11 Info: Alarm-Mask
Alarms Masked: TxAIS Terr REF TxClk BUC
CnC Buffer AGC RxAIS Sat EbNo LNB CEX
This screen displays only the alarm(s) that are currently masked. This example shows all
available parameters as present and operational. For any alarm that is not masked, a blank
space assumes that parameter’s designated screen position.
6.2.4.12 Info: Misc
Miscellaneous: Normal
1:1 Switch=Not connected Online
This screen displays the following information:
Display Item Configuration Setting
Top line Operational Mode Test Mode or Normal.
Bottom line
1:1 Switch Link Status Connected or Not Connected.
Redundancy Status Offline or Online.
